Control Codes 69
Epson LQ Commands (Continued)
Epson Command ASCII Decimal
Character Style
Normal ESC q 0 27 113 48
Outline ESC q 1 27 113 49
Shadow ESC q 2 27 113 50
Outline with Shadow ESC q 3 27 113 51
Delete DEL 127
Double Height On ESC w 1 27 119 49
or ESC US 0 or 27 31 48
Double Height Off ESC w 0 27 119 48
or ESC US 1 or 27 31 49
Double Width On ESC W 1 27 87 49
Double Width Off ESC W 0 27 87 48
Double Width
for One Line SO 14
or ESC SO or 27 14
Emphasized Print On ESC E 27 69
Emphasized Print Off ESC F 27 70
Epson Command ASCII Decimal
Enhanced Print On ESC G 27 71
Enhanced Print Off ESC H 27 72
Italic Printing On ESC 4 27 52
Italic Printing Off ESC 5 27 53
Form Feed FF 12
Form Length
n Inches (n = 1 to 22) ESC C NUL n 27 67 0 n
n Lines (n = 1 to 127) ESC C n 27 67 n
Horizontal Tab HT 9
Initialize Printer ESC @ 27 64
Justification
Left ESC a 0 27 97 48
Center ESC a 1 27 97 49
Right ESC a 2 27 97 50
Full ESC a 3 27 97 51
To Next Page
