Interface Connections (Cabinet And Pedestal)
Interface Connections (Cabinet And Pedestal)
Figure 15. Cabinet Model Interface Connections
1. Remove the cover from the I/O connector you have selected.
2. Attach the I/O cable connector to the printer interface
connector.
RS-422
(if installed)
Diagnostic
Ethernet option (if installed)
or Coax/Twinax (if installed)
9 Pin STD
Serial RS-232
Centronics Parallel
9 Pin to 25 Pin STD
Serial Adapter
Network
10/100 Base-T
Coax/Twinax
A
A
