Checking The Paper Feed – Pedestal Model
50
Checking The Paper Feed – Pedestal Model
Figure 40. Side View of the Pedestal Model Showing Paper Feed Routes
NOTE: When using the top exit paper path, paper cannot be
stacked. Paper is intended to be removed after each print
job is completed.
• For rear paper exit: Press the Paper Advance key several
times to ensure that the paper feeds properly beyond the
tractors, over the paper guide assembly, and through the paper
exit slot in the rear of the cabinet. Ensure that the paper folds
the same way in the stacking area as it does in the supply area.
• For top paper exit: Press the Paper Advance key several
times to ensure that the paper feeds properly beyond the
tractors, over the paper guide assembly, and through the paper
exit slot.
Rear Exit Top Exit
To Next Page
