49
Loading And Starting The Power Paper Stacker
Top Paper Exit
Figure 39. The Quick Access Cover on the Pedestal Model
1. Open the pedestal printer top cover.
2. Unscrew the blue captive screws securing the cover insert to
the top cover.
3. Remove the cover insert and place to the side. Removal of the
cover insert allows you to feed the paper through the top cover,
thus exiting the top of the printer.
NOTE: Do not discard the cover insert. You may use it to close the
paper slot exit and have the paper exit the rear of the
printer.
4. Raise the quick access paper deflector.
5. Rotate the thumbwheel to angle the quick access paper
deflector.
6. Load the paper and feed it through the paper exit slot on the top
of the printer cover.
7. Align the perforation and tear the paper off along the tear bar.
Top Cover
Quick Access
Cover
Quick Access
Paper Deflector
Paper Exit Slot
Blue Captive
Screw (2)
Blue Deflector
Thumbwheel
Quick Access – Pedestal Model
To Next Page
