30 Microline 320/321 Turbo/n
|
3 Pull up on the lock levers and open the tractor covers.
Then, move the right tractor to fit the width of the paper.
32T-27.eps
4 Place the first two holes in the paper over the tractor
pins on either side. Close the tractor covers.
32T-29.eps
5 Move the left tractor to align the edge of the paper with
the appropriate reference mark (1). Then, push back the
lock lever.
32T-29A.eps
6 Adjust the position of the right tractor to center the holes
in the paper on the pins. Then, push back the right lock
lever.
32T-29.eps
1
