76 Microline 320/321 Turbo/n
|
Menu Settings Table (Continued)
For a complete explanation of each menu item, refer to “Using Your Printer, Menu Mode, Explanations of Menu Items.”
The table below shows the items which may appear in the menu. Settings which are engaged at the factory (defaults) are set in
bold italic. Some groups or entries will only appear when a specific emulation is engaged, as noted.
Group Item Settings (Defaults are set in bold italic)
Set-Up 7 or 8 Bits Data Word* 8, 7
(continued) Operator Panel Function Full Operation, Limited Operation
Reset Inhibit No, Yes
Print Suppress Effective Ye s, No
Auto LF No, Yes
Auto CR+ No, Yes
Print DEL Code* No, Yes
SI Select Pitch (10 cpi)+ 17.1 cpi, 15 cpi
SI Select Pitch (12 cpi)+ 20 cpi, 12 cpi
Time Out Print Valid, Invalid
Auto Select No, Yes
Centering Position DEFAULT, MODE 1, MODE 2
* Appears only when the MICROLINE Standard emulation is selected.
+ Appears only when the IBM emulation is selected.
