1-5-41
(2) Detaching and refitting the pad assembly
<Procedure>
1. Open the DP cover.
2. Press both arms of the pad assembly
inwardly with your fingers and then pull out
the pad assembly.
3. Check or replace the pad assembly and refit
all the removed parts.
Figure 1-5-60
Pad assembly
DP cover
Y107330-8 Service Manual
