3
FLOW OF OBSERVATION
} When the ECO mode is set, the halogen bulb turns OFF automatically in about 30 minutes the microscope becomes
unattended.
(Controls Used) (Page)
Set the main switch to “ I ” (ON) and adjust
the brightness.
@Main switch
2Brightness adjustment knob (P. 10)
Engage only the LBD filter.
3LBD filter knob (P. 10,15,16)
Select the light path (trinocular tube).
4Light path selector knob (P. 23)
Place the specimen on the stage.
5Slide holder (P. 19)
6X-/Y-axis knobs (P. 20)
Engage the 10X objective in the light path.
7Revolving nosepiece
Bring the specimen in focus.
8Coarse/fine adjustment knobs (P. 18)
Adjust the interpupillary distance.
Adjust the diopter.
Adjust the light axis.
9Binocular tube (P. 11)
aDiopter adjustment ring (P. 15,22)
bCondenser height adjustment (P. 12)
knob
cCondenser centering knob (P. 12)
Adjust the aperture iris and field iris diaphragms.
dAperture iris diaphragm ring (P. 12)
eField iris diaphragm ring (P. 12)
Engage the objective to be used in the light
path and bring the specimen in focus.
7Revolving nosepiece
8Coarse/fine adjustment knobs (P. 11)
Adjust the brightness.
2Brightness adjustment knob (P. 10)
Engage the required filters.
fFilters (P. 10,16)
Start observation.
To Next Page
