SPECIFICATIONS
Item Specification
1. Optical system UIS2/UIS (Universal Infinity System) optical system (featuring infinity correction)
2. Illumination Built-in transmitted Koehler illumination
FN (Field Number): 26.5 (super-widefield compatible)
12V, 100W long-life halogen bulb (pre-centered) 12V100WHAL-L (PHILIPS 5761)
(Average life time: Approximately 2,000 hr. when used as directed)
Light intensity voltage range: 2 V or less to 12.0 V DC (continuous)
Light intensity preset button (voltage adjustment range: 2 V or less to 12.0 V DC)
Rated voltage: 100-120/220-240 V
$
, 1.8/0.8 A, 50/60 Hz
Power consumption: 140 W
3. Focusing Stage height movement by roller guide (rack & pinion)
Stroke per rotation: 0.1 mm (fine), 17.8 mm (coarse)
Full stroke range: 25 mm
Upper limit stopper
Tension adjustment on coarse focus adjustment knob
4. Revolving nosepiece Type
U-5RE-2 U-D6RE U-P6RE U-D7RES
5-position revolving
nosepiece
Universal 6-position
revolving
nosepiece
Universal 6-position
centered revolving
nosepiece
7-position revolving
nosepiece with
readout function
Installable
modules
None
Transmitted DIC prism,
transmitted light analyzer
5. Observation tube Type
U-BI30-2
U-BI-3/
U-TBI-3-CLI
U-TR30-2 U-TR30NIR
U-TTR-2 U-SWTR-3
Widefield
binocular tube
Widefield tilting
binocular
Widefield trinocular
tube
Widefield tilting
trinocular tube
Super wide-
field trinocular
Field No. 22 26.5
Tube incli-
nation
30°
5°-35°
continuous
30°
5°-35°
continuous
30°
Interpupillary
distance
adjustment
50 mm to 76 mm
Light path
selector
None
3 steps: @ BI 100%
2 BI 20%, Camera 80%
(BI 50%, Camera 50%
for U-TR30NIR and U-TIR-2)
3 Camera 100%
6. Stage Type
U-SVRB-4 U-SVLB-4
Common-axis knobs on bottom right Common-axis knobs on bottom left
Rectangular ceramic-coated, wire-driven stage
Size 156 mm (D) x 191 mm (W)
Movement
mechanism
X- and Y-axis knobs with adjustable tension
Movement range: 52 mm in vertical (Y) direction, 76 mm in horizontal (X) direction
Specimen
holders (single
slide holder)
U-HLST-4 (thick slide holder)
U-HLS-4 (thin slide holder)
Specimen
holders (double
slide holder)
U-HLDT-4 (left opening, thick slide holder)
U-HLD-4 (left opening, thin slide holder)
U-HRDT-4 (right opening, thick slide holder)
U-HRD-4 (right opening, thin slide holder)
