Olympus CX31 Instructions For Use

CX31
CONTENTS
IMPORTANT — Be sure to read this section for safe use of the equipment. — 1-3
1 NOMENCLATURE 4
2 SUMMARY OF BRIGHTFIELD OBSERVATION PROCEDURE 5
3 ASSEMBLY — See this section for the replacement of the light bulb. — 6-7
4 USING THE CONTROLS 8-14
5 TROUBLESHOOTING GUIDE 15-16
7 OPTICAL CHARACTERISTICS 18
4-1 Base..........................................................................................................................................................................................8
Turning On the Bulb Field Iris Diaphragm
4-2 Focusing Block...............................................................................................................................................................9
Adjusting the Coarse Adjustment Knob Tension Simplified Pre-focusing Dial
4-3 Stage..............................................................................................................................................................................10-11
Placing the Specimen Moving the Specimen
4-4 Observation Tube................................................................................................................................................11-12
Adjusting the Interpupillar Distance Adjusting the Tilt Adjusting the Diopter
Using the Eye Shades Using the Eyepiece Micrometer Disk
4-5 Condenser........................................................................................................................................................................13
Centering the Field Iris Diaphragm Aperture Iris Diaphragm
4-6 Immersion Objectives............................................................................................................................................14
Using the Immersion Objectives
PROPER SELECTION OF THE POWER SUPPLY CORD..................................................19-20
6 SPECIFICATIONS 17
Page
1 2
1 2
1 2
1 2
4 5
1
2
1
3

Olympus CX31 Specifications

General

Type	Biological Microscope
Observation Method	Brightfield
Objective Lenses	4x, 10x, 40x, 100x (Oil)
Focus	Coaxial coarse and fine focus knobs
Weight	Approx. 7 kg
Eyepiece	10x
Nosepiece	Quadruple
Stage	Mechanical stage
Illumination	Built-in illumination
Condenser	Abbe condenser N.A. 1.25 with aperture diaphragm
Illumination Type	LED
Power Supply	AC 100-240V, 50/60Hz
Optical System	UIS2 (Universal Infinity System)
