Set the main switch to “ ” (ON) and adjust
the brightness.
@Main switch (P. 7)
²Light intensity knob (P. 7)
(Controls Used) (Page)
Place the specimen on the stage.
Engage the 10X objective in the light path.
Bring the specimen in focus.
Adjust the interpupillary distance.
Adjust the diopter.
Adjust the light axis.
Adjust the aperture iris and field iris
diaphragms.
Engage the desired objective in the light path
and bring the specimen in focus.
Insert the required filters.
Adjust the brightness.
Start observation.
SUMMARY OF BRIGHTFIELD OBSERVATION
PROCEDURE
22
ƒRevolving nosepiece
…Coarse/fine focus adjustment knobs (P. 8)
†Binocular tube (P 10)
‡Diopter adjustment ring (P. 11)
ŠCondenser height adjustment knob (P. 12)
‰Auxiliary lens centering knob (P. 12)
‹Aperture iris diaphragm knob (P. 13)
ŒField iris diaphragm ring (P. 7)
ƒRevolving nosepiece
…Coarse/fine focus adjustment knobs (P. 8)
™Filters (P. 13)
²Light intensity knob (P. 7)
³Specimen holder (P. 9)
|X-axis/.Y-axis knobs (P.10)
