Information
13
121
EN
•
Use the hood when shooting a backlit subject.
•
The lens hood cannot be attached to the 17.5 – 45 mm lens.
Main Specifications
Can be used with the optional EX-25 extension tube under the following conditions.
The focus adjustment when EX-25 is used will be MF.
Attaching the hood
Storing the hood
Items 17.5 – 45 mm 14 – 42 mm 40 – 150 mm 25 mm
Mount FOUR THIRDS mount
Focal length 17.5 – 45 mm 14 – 42 mm 40 – 150 mm 25 mm
Max. aperture f3.5 – 5.6 f3.5 – 5.6 f4.0 – 5.6 f2.8
Image angle 63° – 27° 75° – 29° 30° – 8.2° 47°
Lens configuration
7 groups,
7 lenses
8 groups,
10 lenses
9 groups,
12 lenses
4 groups,
5 lenses
Multilayer film coating (partially single layered)
Iris control f3.5 – 22 f3.5 – 22 f4.0 – 22 f2.8 – 22
Shooting range 0.28 m –
)
0.25 m –
)
0.9 m –
)
0.2 m –
)
Focus adjustment AF / MF switching
Weight (excluding hood
and cap)
210 g 190 g 220 g 95 g
Dimensions
(Max. diameter x overall
length)
Ø
71 x 70 mm Ø
65.5 x 61 mm Ø
65.5 x 72 mm Ø
64 x 23.5 mm
Lens hood mount
k
Bayonet Screw-in type
Filter mount thread
diameter
52 mm 58 mm 43 mm
