Olympus IX71 - Phase Contrast Observation (IX2-ILL30); Phase Contrast Optical Elements

32
}A phase contrast objective, phase contrast optical element and the U-CT30 centering telescope (which is not required
when the U-BI90CT binocular observation tube is used) are required for phase contrast observation.
}If a DIC slider, analyzer and/or polarizer are engaged in the light path, disengage them.
OTHER OBSERVATION METHODS
5-1 Phase Contrast Observation (Using the IX2-ILL100 Column)
With the IX2-LWUCD or IX2-LWUCDA2 Condenser
Optical Element Indication Applicable Objectives
IX-PHL (small) PhL UPlanFl4XPh
IX-PHC (small) PhC CPlan10XPh, LCAch20XPh, CPlanFl10XPh
IX-PH1 (small) Ph1 UPlanFl10XPh, UPlanFl20XPh, LCPlanFl20XPh, UPlanApo10XPh
IX-PH2 (small) Ph2 UPlanFl40XPh, LCPlanFl40XPh, LCPlanFl60XPh, UPlanApo20XPh,
LCAch40XPh, LUCPlanFl40XPh, SLCPlanFl40XPh
IX-PH3 (large) Ph3 UPlanFl100XO3Ph, UPlanApo40XOI3Ph, UPlanApo100XOI3Ph, PlanApo60XO3Ph
}Insert the optical element (small) in the 30 mm position and the optical element (large) in the 38 mm position.
For well observation, it is recommended to use the IX-PHC to obtain the phase contrast effect in a wide range of field of
view.
1
Phase Contrast Optical Elements and Applicable Objectives
Optical Element Indication Applicable Objectives
IX-PHL (small) PhL UPlanFLN4XPh
IX-PHC (small) PhC CPlanN10XPh, LCAchN20XPh, CPlanFLN10XPh
IX-PH1 (small) Ph1 UPlanFLN10X2Ph, UPlanFLN20XPh, LUCPlanFLN20XPh
IX-PH2 (small) Ph2 UPlanFLN40XPh, LUCPlanFLN40XPh, LUCPlanFLN60XPh,
LCAchN40XPh, UPlanFLN60XOIPh
IX-PH3 (large) Ph3 UPlanFLN100XO2Ph
UIS2 Series
UIS Series
