Olympus IX81 - Specifications

46
IX81
SPECIFICATIONS
Module
Specification
Microscope
Frame
IX81-S8F-3
IX81-S1F-3
IX81-F-3
· Motorized light path selection S8F-3: Side port 80% light path
S1F-3: Side port 100% light path
F-3: Prism unit is required.
· Motorized 6-position revolving nosepiece (DIC slider attachable)
· Motorized focusing up/down stroke: Above focusing position: 7 mm. Below
focusing position: 2 mm
· Side port: 1X (perfect aberration correction)
· Intermediate magnification changer: 1X 1.6X built in
· Selector buttons:
Light path selector, coarse/fine selector (x 2), light intensity control, focusing
, focusing , objective escape/return (x 2), lamp on-off, auxiliary
Illumination
Column
IX2-ILL100
Column for installing the lamp housing, with 30° tilting mechanism.
Condenser holder can be flipped up.
For 100 W halogen bulb, precentered.
Observation
Tube
U-BI90CT Binocular tube with 45° tilting angle. Built-in CT, diopter adjustment on one
eyepiece sleeve possible. Eye point switchable in 2 steps of 400 and 430
mm.
U-BI90 Binocular tube with 45° tilting angle. Diopter adjustment on one eyepiece
possible. Eye point switchable in 2 steps of 400 and 430 mm.
U-TBI90 Binocular tube with 35° to 85° tilting angle. Diopter adjustment on one eyepiece
possible. Eye point 406 to 471 mm.
U-TR30H-2 Trinocular tube with 30° tilting angle. Can be installed by means of the IX-ATU
intermediate tube. Eye point 434 mm
Condenser IX2-LWUCDA2, IX2-LWUCD N.A. 0.55, W.D. 27 mm. Motorized turret: 6 positions / Manual turret: 5 positions.
IX-ULWCD N.A. 0.3, W.D. 73 mm. Manual turret with 4 positions.
U-UCD8
Dry: N.A. 0.9, W.D. 1.5 mm.
Oil immersed: N.A. 1.4, W.D. 0.6 mm
Stage IX2-SFR
Coaxial flexible knobs on the bottom right position. Movement range 50 mm
(X) x 50 mm (Y). Center plate diameter 110 mm.
IX-SVL2 Coaxial knobs on the bottom left position. Movement range 50 mm (X) x 43 mm
(Y). Center plate diameter 110 mm.
IX2-SP, IX-MVR Size 232 mm (X) x 240 mm (Y). Coaxial flexible knobs on the bottom side.
Movement range 130 mm (X) x 85 mm (Y). Center plate diameter 110 mm.
Eyepieces WHN10X Field number 22.
WHN10X-H Field number 22, with diopter adjustment helicoid.
35WHN10X Field number 22, with 35 mm film photo mask and diopter adjustment helicoid.
