Preparation for Use
MOBILE WORKSTATION WM-NP2
49
4.7 Keyboard assembly
1. Referring to Figure 4.27, fully extend the keyboard tray, feed the keyboard cable through the
cutout and place the keyboard on the keyboard tray as shown.
2. Referring to Figure 4.28, route the keyboard cable as shown and secure to the fixing bracket
with a single cable tie.
CAUTION
Ensure the cable passes around the outside of the sliding runner,
otherwise the cable may be pinched when operating the sliding tray.
Figure 4.27
Figure 4.28
