Preparation for Use
MOBILE WORKSTATION WM-NP2
35
8. Fit the cable tie and cable ducts that were removed in step 3. Position the cable duct against
the shelf, align the cable tie (with stud removed) with the shelf hole, and press the stud all the
way through the cable tie into the hole to secure the cable duct.
4.4 Fixing position of the drawer unit
If you purchase the set containing a drawer unit, it is delivered with the drawer unit already fitted.
Use the following steps to reposition the drawer unit.
1. Position the workstation on a flat surface and apply both castor brakes.
2. Empty the contents of the drawer.
3. From the rear of the workstation, remove the four M8 screws, M8 crinkle washers and M8
plain washers securing the drawer (Figure 4.8).
Figure 4.7
