Operation
MOBILE WORKSTATION WM-NP2
56
1. Place the mobile workstation on a flat surface and lock the Castor Brakes.
2. Plug the power cord of the mobile workstation into an adjacent wall outlet socket.
3. Confirm that the indicator on the remote switch lights yellow.
4. When the remote switch is ON, confirm that the indicator lights green.
5. For use of Optional accessories, please refer to each accessory instruction manual.
6. After use, turn off the remote switch.
7. If it is anticipated that the system will not be used for a significant period of time, disconnect
the transformer cable from the wall outlet socket to conserve energy and hang it on the cable
hook on the back of the top tray.
5.2 Manoeuvring
• If the product has to be taken out of the room, use 2 people to
manoeuvre it. Take particular care to manoeuvre it correctly when
moving up or down slopes.
• Before attempting to move the workstation outside the procedure room,
ensure that the endoscope and fluid containers are removed.
• Ensure each drawer is locked when moving the workstation.
1. Disconnect the transformer cable from the wall outlet socket and hang it on the cable hook
on the back of the top tray.
2. Remove the endoscope and the water container from the product.
3. Check that the mounted device is stable.
4. Put the accessories into their respective storage positions. In particular, if the LCD arm is
fitted, put it in its parked position and rotate it so that it does not impede the movement of the
LCD monitor.
5. Move the product by gripping the handles on the front, sides and back of the top tray.
Figure 5.1
