Specifications
MOBILE WORKSTATION WM-NP2
62
Chapter 7 Specifications
7.1 WM-NP2 mobile workstation
7.2 Separation transformer
Product name WM-NP2 mobile workstation
Dimensions (mm) Height: 1370 (scope in lowest position)
2140 (scope in highest position)
1169 (to top tray)
2073 max (with 26” LCD monitor in highest position)
Depth: 700
Width: 650
Weight 85kg unladen, including fitted transformer.
Load capacity
(evenly distributed)
Top tray 20kg
Intermediate shelves 30.5kg each
Base panel 30kg
NOTE: Equipment stored on the mobile workstation should not exceed
the size of the shelf.
Castors 4 x 125mm antistatic, two with brakes.
Ambient temperature Storage: -40°C to +70°C (-40°F to +158°F)
Operation: 10 - 40°C (50 - 104°F)
Relative humidity 95% maximum @ 40°C (104°F) non-condensing
Atmospheric pressure Storage: 23.5-106 kPa (3.4-15.37lbf/in
2
)
Operation: 70-106 kPa (10.15-15.37lbf/in
2
)
Product name Olympus Separation Transformer
Identification Market Japan USA UK, Europe,
Rest of the world
Model No. MAJ-1646 MAJ-1647 MAJ-1648
Part No. K10020331 K10020332 K10020333
Power input
requirements
Input voltage 100V 110-120V 220-240V
Frequency 50/60Hz 60Hz 50/60Hz
Power input (max) 1350VA 1300VA 1900VA
Power cable part No. K10001001 K10001002 K10001003 (UK)
K10001004 (Europe)
K10001005 (RoW)
Power output Maximum load 1250VA * 1250VA 1800VA
* Maximum 10A load per IEC socket outlet (MAJ-1646 only)
Overload
protection
Circuit breakers
(dual circuit, single actuator)
2 x 15A 2 x 13A 2 x 9A
Potential
equalisation
Terminals fitted 1 at input
