Preparation for Use
MOBILE WORKSTATION WM-NP2
32
4.3 Fixing positions of intermediate shelves
The product columns contain holes for the intermediate shelves. You can reposition the shelves to
suit the size of the equipment being mounted.
 On delivery
The product is delivered with the shelves fitted in the positions shown in Figure 4.4.
Figure 4.4
Shelf fixing holes
25mm apart
292mm
35mm
35mm
215mm
275mm
Drawer unit not shown
