Preparation for Use
MOBILE WORKSTATION WM-NP2
40
4.5 Clip-in accessories
1. The workstation is provided with a standard range of pre-fitted clip-in accessories. These can
be re-positioned in any of the accessory ports located on the sides of each shelf as shown in
Figure 4.16.
The accessory ports are ‘keyed’ and clip-in accessories (except the blanking cap) will only fit
one way.
To remove a clip-in accessory, squeeze the clip section together from beneath the shelf and
push into the port and remove.
Blanking caps are provided for each unused accessory port. If additional
accessories are fitted, the appropriate blanking cap will not be required
and should be stored in case of future use.
Figure 4.15
Figure 4.16
