Care, Inspection, Storage and Maintenance
MOBILE WORKSTATION WM-NP2
59
2. Refer to the steps described in Figure 6.1 when removing the drawer from the housing.
(i) Pull the drawer out as far as possible.
(ii) Press the release levers on each side of the drawer in the direction of the arrows.
(iii) Open the drawer again and remove from the housing.
6.2 Inspection
Should the slightest irregularity be suspected, do not use the mobile
workstation and refer to Chapter 10 Troubleshooting. If the problem
cannot be resolved, contact Olympus for service.
Regular inspection is important to prevent risk to the user.
1. Check the power supply cable and plug for excessive protrusion, twists, deformation or other
irregularities. Refer to section 6.4 Maintenance if the power supply cable needs to be
replaced.
2. When the transformer cable is connected to a nearby wall outlet socket, check that the
‘mains power connected’ LED on the transformer illuminates green.
Figure 6.1
Release lever
Housing
Drawer
