Omega Engineering i Series User Manual

ENTER READING CONFIGURATION MENU:
Press
a
1) Press
a
, if necessary, until
CNFG
prompt appears.
Press
d
2) Display advances to
INPT
Input Menu.
Press
a
3) Display advances to
RDG
Reading Configuration Menu.
Press
d
4) Display advances to
DEC
Decimal Point.
DECIMAL POINT SUBMENU:
Press
d
5) Display flashes previous selection for Decimal location.
Press
b
6) Scroll though the available selections and choose Decimal
location:
FFFF
,
FFF.F
,
FF.FF
or
F.FFF
Press
d
7) Display shows
STRD
stored message momentarily only, if
changes were made, otherwise press
a
to advance to
LOAD
Known/Unknown Loads Submenu.
Decimal Point is passive.
KNOWN/UNKNOWN LOADS SUBMENU:
Press
d
8) Display flashes previous selection of
ENBL
Enable or
DSBL
Disable.
Press
b
9) Scroll though the available selection of
ENBL
or
DSBL
(flashing).
Press
d
10) Display shows
STRD
stored message momentarily and then
advances to L.PNT Linearization Points Submenu.
If
ENBL
Known Loads scaling method was selected, calculate
the input values to the instrument based on the actual signal
being received. If
DSBL
Without Known Loads scaling method
was selected, calculate input values to the instrument based on
the transducer specification.
LINEARIZATION POINTS SUBMENU:
Press
d
11) Display flashes previous selection of Linearization Points
Submenu.
Press
b
12) Scroll though the available selections:
0002
,
0003
,
0004
,
0005
,
0006
,
0007
,
0008
,
0009
,
0010
- up to 10
Linearization Points can be selected. Default is
0002
.
If display flashes
NONE
, your instrument has only 2 linearization
points.
Press
d
13) Display shows
STRD
stored message momentarily only, if a
change was made, otherwise press
a
to advance to the
FLTR
Filter Constant Submenu.
Linearization Points allow users to customize the Transducer curve.
19
