Omega FMA 5400A - Page 49

44
0.95
SAE/MS Swagelok
3/8 Tube Connector
2.38
7" (177,8)
9.98 (253,5)
12.30 (312,4)
* 10-24 UNC-2B
0.18 (4,6)
1.75 (44,5)
1.39 (35,3)
1" (25,4)
4.69 (119,1)
2.15 (54,6)
2.72 (69,1)
6.9" (175,3)
1" (25,4)
0.875 (22,2)
* For units purchased prior to August 15, 2012 thread size = 6-32 UNC-2B
SERIES MAX FLOW 200 L/min MASS FLOW CONTROLLER
NOTE: OMEGA reserves the right to change designs and dimensions at its sole discretion at any time
without notice. For certified dimensions please contact OMEGA.
50.00
valve
ontrol
ontrol
l
(76,2 mm)
3.00
(76,2 mm)
3.00
(191,8 mm)
7.55
7.25 (184,1 mm)
10.24 (260,1 mm)
12.62 (320,5 mm)
(191,8 mm)
7.55
10.24 (260,1 mm)
12.62 (320,5 mm)
control
CE
flow
(63,5 mm)
2.50
6.75 (171,5 mm)
(63,5 mm)
2.50
August 15, 2012 thread size = 8-32 UNC-2B* For units purchased prior to
1/4-20 UNC-2B *
2 x 1/2 compression fittings
August 15, 2012 thread size = 8-32 UNC-2B
SERIES MAX FLOW 500 L/min MASS FLOW CONTROLLER
