omi ED 270 - Page 74

Cod. 710.0138.01.00 Rev1C – 09.2009 72 - 75
Mod. 270 – 360 – 480 Nm3/h
(Mod. 4500 – 6000 – 8000 Nl/min)
Mod. 660 - 780 - 1000 Nm3/h
(Mod. 11000 - 13000 - 16667 Nl/min)
Mod. A B C D E F G H I L
270 - 480
503 604 980 100 254 157 5 115 - -
1-1/2"
GAS
1-1/2"
GAS
Ø 6mm
V/ph/Hz
230/1/50
230/1/60
660
720 750 1340 109 346.5 180 60 148.5 105.5 29
2"
GAS
2"
GAS
780 - 1000
720 750 1360 109 346.5 180 60 148.5 105.5 29
2"
GAS
2"
GAS
400/3/50
460/3/60
V/ph/Hz
IN
OUT
IN
OUT
