CP CR500
14
4.2 Connecting CPC 100 to CP TD1
First, connect CPC 100 with CP TD1 as follows:
1. Switch off CPC 100 at the main power switch.
2. Properly connect the CPC 100's and CP TD1's grounding terminals to earth.
Use cables of at least 6 mm² cross-section.
3. Connect CP TD1's "BOOSTER IN" to CPC 100's "EXT. BOOSTER". Use
only the booster cable supplied by OMICRON.
4. Connect CP TD1's "SERIAL" to CPC 100's "SERIAL". Use only the data
cable supplied by OMICRON.
The data cable also provides the power supply for CP TD1.
4.3 Connecting the CP CR500 to a CPC 100
(Safety Circuit)
1. Remove the dongle from CPC 100’s "connector for external safety functions"
(at the right side of CPC 100).
2. Connect the Safety A connector at the CP CR500 interface panel to
CPC 100’s connector for external safety functions using the modem cable
(length 9 meter).
3. Terminate the Safety B connector at the CP CR500 interface panel with the
CPC 100 dongle that is normally plugged in at the CPC 100’s connector for
external safety functions.
If you use two CP CR500, please refer to 4.6 ”Connecting Two CP CR500
Units in Parallel” on page 16.
