1-6 Electronics Sled
Printer Removal
OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
8. Disconnect the printer ribbon cable and the printer data cables from the printer PC Board.
Figure 1-10. Remove the printer cables
9. Remove the printer.
Figure 1-11. Remove the printer
A
B
