Drawers 3-5
Supply Drawer Installation
In Figure 3-3, the bin in the lower right corner of the drawer would be Bin 7, the bin in the upper
left corner would be Bin 49, and the bin in the upper right corner would be Bin 85.
Once a bin has been configured, label the bin divider to correspond with the bin name corner. and
affix the label to the top of the right rear divider of that bin.
Supply Drawer Installation
1. Perform a graceful shutdown of the electronic sled.
2. Open the door in the zone where the supply drawer will be located.
3. Slide the two drawer brackets into the slots in the back of the frame.
4. Secure the slide mounting bracket to the frame with the screw provided. Use a Torx T15
screwdriver to tighten the screw.
5. Slide the supply drawer and housing onto the brackets until the drawer snaps into the latching
tabs located on the back of the bracket.
6. Connect the SPC board cable to the 10-pin connector on the rear of the SPC board in the
wireway of the frame.
7. Use a Torx T15 screwdriver to insert two screws - one on either side of the bottom of the
drawer - to secure the supply drawer to the drawer brackets.
8. Insert the switchpanel connector cover into the hole in the frame.
9. Set the DIP switches for the shelf and the zone settings. There are two DIP switches: The first
DIP switch (S1) sets the drawer zone and the second DIP switch (S2)sets the drawer location.
Pharmacy Drawer Installation
1. Unlock the manual override cover using the #2302 and 2232 keys.
2. Remove the cover by pushing it to the right and lifting it off.
3. Remove any false drawer front by removing the two screws securing the false drawer front
using a Torx T15 screwdriver.
Note:
On switch S1, switch #8 must always be off for a supply drawer SPC.
Important: A Pharmacist must be present when servicing drawers where medications are present.
