OmniCell OmniRx - Page 48

A-4 Appendix A: Part List
OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
92-1000
92-1002
92-1011
key CAM LOCK,#2036 [lid]
CAM LOCK,#2202 [manual ovveride cover]
CAM LOCK,#2232 [manual ovveride cover]
General Shutdown
Wireway Removal
Pharmacy Drawer
Installation
Pharmacy Drawer
Removal
94-6005 (keyboard cover) nut NUT,HEX,4-40,SS
PS/2 Keyboard
USB Keyboard
94-6132 (supply drawer) screw
(drawer controller cable cover)
screw
SCREW,BH,TORX,8-32,X,3/16,SS
Supply Drawer
Installation
Pharmacy Drawer
Removal
94-6133 (slide mounting screw
(wireway) screw [front, side]
(manual override assembly)
screw
(clamp) screw
SCREW,BH,TORX,8-32,X,1/4,SS
Wireway Removal
Pharmacy Drawer
Installation
Manual Override
Cable Service
94-6137 (speaker) screw SCREW,BH,TORX,6-32,X,3/16,SS
Speaker Removal
94-6142 (manual override cable) screw SCREW,BH,TORX,4-40,X,1/4,SS
Manual Override
Cable Service
94-6162 (LCD bezel) screw
(printer cover) screw
(printer assembly) screw
(console) screw
(cable cover bracket) screw
SCREW,FH,TORX,6-32,X,3/16,100,DEG,C'SINK
LCD Screen
Removal
Seiko Printer
APS Printer
Manual Override
Cable Service
Standardization
Changes
94-6165 (false drawer front) screw SCREW,BH,TORX,8-32,X,3/8,SS
Pharmacy Drawer
Installation
94-6167 (manual override cable) nut NUT,EX,SMALL,HEX,10-32,1/4,X 3/32,SS
Manual Override
Cable Service
94-6170 (electronics sled) fastener STUD,1/4,TURN,WING,HD,SOUTHCO
PowerCom2 Tray
94-6173 (PC card) screw SCREW,SHCS,4-40,X,3/16,SS
Seiko Printer
APS Printer
95-6015 paper PAPER,THERMAL,92M ROLL,80MM WIDE
Seiko Printer
APS Printer
Part # Part Name Agile Description Where Used
Table A-1. OmniRx Part List
