OmniCell OmniRx - Page 47

© 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D
Appendix A: Part List A-3
53-2081 drawer controller cable cover COVER,CABLE,OMNIRX
Pharmacy Drawer
Removal
53-2082 manual override cover COVER,MANUAL,OVERRIDE,OMNIRX
Wireway Removal
Pharmacy Drawer
Installation
Pharmacy Drawer
Removal
53-7104
53-7123
slide mounting bracket BRACKET,SLIDE,MOUNT,OMNIRX
BRACKET,SLIDE,MOUNT,MAN. OVERRIDE,ATTACH
Wireway Removal
Supply Drawer
Installation
Pharmacy Drawer
Installation
53-7106 cable clamp CABLE,CLAMP,SLIDE,MOUNT,OMNIRX
Pharmacy Drawer
Installation
Pharmacy Drawer
Removal
53-7128 override lever LEVER,MANUAL OVERRIDE RELEASE,3-DRAWER CARRIER
Pharmacy Drawer
Removal
53-7286 keyboard support bracket BRACKET,MOUNTING,KEYBOARD,OMNIRX
USB Keyboard
53-7288 keypad support bracket BRACKET,MOUNTING,NUMERIC KEYPAD,OMNIRX
USB Keyboard
57-7231 light pipe LIGHT PIPE, 2222, 3131,96 SDD
Lit Matrix Drawers
57-7035
57-7046
bin liner LINER,MATRIX,96-BIN,RX
LINER,MATRIX,4-BIN,RX,VACUUM FORMED
Double-Deep
Matrix Drawer
70-7000
70-7002
(printer) ribbon cable
(flex cable hard wired to printer)
PRINTER,THERMAL,SEIKO LTP3345A-S576
PRINTER, THERMAL, APS CP305-80MM-BL-OMN
Seiko Printer
APS Printer
71-1145 elastomer OVERLAY, ELASTOMER, QWERTY, ENGLISH, CTPC
PS/2 Keyboard
71-1188 keypad overlay OVERLAY,ELASTOMER,KEYPAD,LOW PROFILE,NUMERIC,GREY
USB Keyboard
71-1189 keyboard overlay OVERLAY,ELASTOMER,QWERTY, LOW PROFILE, ENGLISH
USB Keyboard
71-3001
71-3008
switchpanel connector cover SWITCHPANEL,DRAWER,GREEN
SWITCHPANEL,DRAWER,BLUE
Supply Drawer
Installation
73-1001 speaker SPEAKER, 2.5", 8 OHM, 2W
Speaker Removal
80-0374 DIP switch SW,DIP,8-POS,SL,SPST,VERT,TH
Supply Drawer
Installation
80-0802 speaker cable CONN,CABLE ASSY,MOLDED PLUG,3.5MM STEREO,SHL'D,PVC,36IN
Speaker Removal
82-6061 jumper JUMPER,SHUNT,0.1",15AU,RED
Standardization
Changes
91-7040 drawer slide SLIDE,OUTER HALF, DRAWER,RX,ACCURIDE C3834-156-1 [right side]
Wireway Removal
Part # Part Name Agile Description Where Used
Table A-1. OmniRx Part List
