A-2 Appendix A: Part List
OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
15-7075
15-7076
divider (kit) KIT,DIVIDER,24-BIN,LIT,MATRIX
KIT,DIVIDER,4/96,BIN,UNLIT,MTR
Bin Configuration
40-1045
71-7008
PC card PCBA, PRINTER INTERFACE, APS
PCB ASSY,PRINTER,RIGHT ANGLE SHROUDED CONN (Seiko)
Seiko Printer
APS Printer
40-7035 wireway cable PCB ASSY,RX,DRAWER,CONNECT OMNIRX
PowerCom2 Tray
41-1034 keyboard PCB PCB,KEYBOARD,QWERTY,USB KB,PS/2 MSE,84-KEY,CTPC
USB Keyboard
41-1035 keypad PCB PCB,KEYBOARD,NUMERIC,USB KB,PS/2 MSE,23-KEY,CTPC
USB Keyboard
41-7009 (wireway) SPC Board PCB,RX,DRAWER,CONNECT RX
Wireway Removal
42-1185 cabinet power cable CABLE,ASSY,POWER,SWITCH
PowerCom2 Tray
42-1204 card reader cable CABLE,ASSY,POWER,CARD,READER CT,PC,BOX
PowerCom2 Tray
42-1210 fan power cable CABLE,ASSY,FAN RETROFIT COOLING,OMNIRX
PowerCom2 Tray
42-1229 flat panel cable; LCD data cable CABLE ASSY, LVDS LCD DISPLAY
LCD Screen
Removal
42-1232 battery cable CABLE,ASSY,BATTERY,18V,UPS,CT PC BOX,POWERCOM3
General Shutdown
42-1302-02 [USB keyboard] power cable CABLE,ASSY,USB KEYBOARD,QWERTY TO MOTHERBOARD,STD,CTPC
USB Keyboard
42-1304 (printer) power cable CABLE ASSY, POWER, APS PTR, CT PC BOX
APS Printer
42-1307 [keypad/keyboard] ribbon cable CABLE ASSY,NUMERIC TO KEYBD, OMNIRX/TT
USB Keyboard
42-2101 SPC board cable CABLE,ASSY,DRAWER,CONTROLLER TO,SPC
Supply Drawer
Installation
42-7030 drawer cable CABLE,ASSY,DRAWER,OMNIRX
Pharmacy Drawer
Removal
42-7061 touch screen cable CABLE,ASSY,TOUCH,PAD,DATA ANESTHESIA
PowerCom2 Tray
42-7087 contrast cable CABLE ASSEMBLY, POTENTIOMETER, OMNIRX
PowerCom2 Tray
42-7088-12
42-7096-12
data cable
(sensors hard wired to printer)
CABLE ASSY,PRINTER,48" (Seiko)
CABLE ASSY, PRINTER, 34 PIN, 48" (APS)
Seiko Printer
APS Printer
42-7092 inverter cable CABLE ASSY,ETX-REV C TO INVERTER,121PW181,RX
LCD Screen
Removal
51-2064 manual override handle KNOB,PULL,MANUAL,OVERRIDE OMNIRX
Manual Override
Cable Service
51-7025 manual override cable CABLE,MANUAL OVERRIDE,OMNIRX
Manual Override
Cable Service
53-2081
53-7289
cable cover bracket COVER,CABLE,OMNIRX [old]
COVER,CABLE,OMNIRX [new]
Standardization
Changes
Manual Override
Cable Service
53-1082 keyboard cover BKT,COVER,KEYBD,OMNIRX
PS/2 Keyboard
53-1105 LCD bezel BEZEL, NEC LVDS LCD DISPLAY
LCD Screen
Removal
53-2078 wireway WIREWAY,OMNIRX
Wireway Removal
Part # Part Name Agile Description Where Used
Table A-1. OmniRx Part List
