OmniCell OmniRx - Appendix A: Part List

© 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D
A-1
Appendix A: Part List
Link back to the procedure that calls out the given part using the cross reference in the Where Used
column.
Part # Part Name Agile Description Where Used
12-3102
12-3113
supply drawer DRAWER ASSY,SUPPLY,OSD24,GREEN BUTTONS
DRAWER ASSY,SUPPLY,OSD24,BLUE BUTTONS
Supply Drawer
Installation
13-1128-58 PowerCom2 tray MFG ASSY,CT PC BOX,W/PTR, 5.8 XP ETX CE [inactive]
PC Tray Upgrade
13-1129
13-1142
13-1136
13-1143
13-1150
13-1152
13-1151
13-1153
console MFG ASSY, LID, ETX, LVDS, RX-CT (old)
MFG ASSY, LID, LVDS, RX-CT, MOBILE CART (old)
MFG ASSY,LID W/O PTR,CE (old)
MFG ASSY, LID W/O PTR, MOBILE CART (old)
MFG ASSY, LID, ETX, LVDS, RX-CT (new)
MFG ASSY, LID, LVDS, RX-CT, MOBILE CART (new)
MFG ASSY,LID W/O APS PTR,CE (new)
MFG ASSY, LID W/O APS PTR, MOBILE CART (new)
Keyboard Service
Standardization
Changes
14-1122 keyboard MFG,ASSY,KEYBOARD/LCD,W/PTR OMNIRX
PS/2 Keyboard
14-1123
14-1291
printer, printer assembly
(printer) ribbon cable
[hard wired to printer, same P/N
as printer]
MFG,ASSY,PRINTER,OMNIRX (old)
MFG ASSY,APS PRINTER,OMNIRX (new)
Seiko Printer
APS Printer
14-1261 LCD assembly MFG ASSY, DISPLAY,ETX-REVC,LVDS,RX-CT
LCD Screen
Removal
14-2040 PowerCom3 tray ELECTRONICS TRAY,ETX2,5.10.1.9,ANESTHESIA
PC Tray Upgrade
14-7008
14-7009
14-7013
14-7015
14-7016
pharmacy drawer MODEL,OLL6,LARGE,LOCKING DRAWER,RX2
MODEL,OSL6,LARGE,SENSING DRAWER,RX2
MODEL,OSL12,REGULAR,SENSING DRAWER,RX2
MODEL,OSL24,24-BIN,SENSING DRAWER,RX2
MODEL,OLMD24,24-LIT,MATRIX MATRIX,DRAWER
Pharmacy Drawer
Installation
14-7021 double-deep matrix drawer
bin labels [comes with drawer]
MODEL OMD4,4-BIN MATRIX DRAWER,UNLIT
Double-Deep
Matrix Drawer
Matrix Drawers
Labels
15-7020 false drawer front MFG,ASSY,DRAWER,FRONT,DUMMY RX2
Pharmacy Drawer
Installation
Table A-1. OmniRx Part List
