Parameters Affected by Rated Current [%]
In the case of parameters for which a current value is set, the parameter's default data and setting
range are restricted by the rated current of the inverter.
When you set those parameters, set a percentage [0.01% unit] of the inverter rated current in the DrivePro-
gramming program.
The following are representative examples of parameters whose rated current is included in the data.
For details, refer to the 9-5 Modbus Communication Register Number List in the High-function Gen-
eral-purpose Inverter 3G3RX2 Series User's Manual (I620).
Parameter
No.
Description Data
AF136 Brake Release Current Setting, 1st-
motor (Forward side)
0.00 to 200.00(%) (Inverter rated current ratio)
AF143 Brake Release Current Setting, 1st-
motor (Reverse side)
0.00 to 200.00(%) (Inverter rated current ratio)
bA121 Over current suppress Level, 1st-motor 0.00 to 200.00(%) (Inverter rated current ratio)
bA123 Overload restriction 1 active level, 1st-
motor
20.00 to 200.00(%) (Inverter rated current ratio)
bA127 Overload restriction 2 active level, 1st-
motor
20.00 to 200.00(%) (Inverter rated current ratio)
bb-43 Restart level of Active frequency match-
ing
0.00 to 200.00(%) (Inverter rated current ratio)
bb-46 OC-supress level of Active frequency
matching
0.00 to 200.00(%) (Inverter rated current ratio)
bb160 Over current detection level, 1st-motor 20.00 to 220.00(%) (Inverter ND rated current ratio)
bC110 Electronic thermal level setting, 1st-
motor
0.00 to 300.00(%) (Inverter rated current ratio)
bC121 Free electronic thermal current-1, 1st-
motor
0.00 to 300.00(%) (Inverter rated current ratio)
bC123 Free electronic thermal current-2, 1st-
motor
0.00 to 300.00(%) (Inverter rated current ratio)
bC125 Free electronic thermal current-3, 1st-
motor
0.00 to 300.00(%) (Inverter rated current ratio)
CE102 Low current detection level 1, 1st motor 0.00 to 200.00(%) (Inverter rated current ratio)
CE103 Low current detection level 2, 1st motor 0.00 to 200.00(%) (Inverter rated current ratio)
CE106 Over current detection level 1, 1st motor 0.00 to 200.00(%) (Inverter rated current ratio)
CE107 Over current detection level 2, 1st motor 0.00 to 200.00(%) (Inverter rated current ratio)
PA-23 Output current monitor optional output
value setting
0.00 to 300.00(%) (Inverter rated current ratio)
AF236 Brake Release Current Setting, 2nd-
motor (Forward side)
0.00 to 200.00(%) (Inverter rated current ratio)
AF243 Brake Release Current Setting, 2nd-
motor (Reverse side)
0.00 to 200.00(%) (Inverter rated current ratio)
bA221 Over current suppress Level, 2nd-motor 0.00 to 200.00(%) (Inverter rated current ratio)
bA223 Overload restriction 1 active level, 2nd-
motor
0.00 to 200.00(%) (Inverter rated current ratio)
bA227 Overload restriction 2 active level, 2nd-
motor
20.00 to 200.00(%) (Inverter rated current ratio)
bb260 Over current detection level, 2nd-motor 20.00 to 220.00(%) (Inverter ND rated current ratio)
bC210 Electronic thermal level setting, 2nd-
motor
0.00 to 300.00(%) (Inverter rated current ratio)
bC221 Free electronic thermal current-1, 2nd-
motor
0.00 to 300.00(%) (Inverter rated current ratio)
