7 Precautions for Use of Parameters for DriveProgramming
7 - 8
DriveProgramming User’s Manual (I622-E1)
7-3 Parameters Affected by PID
Enabled/Disabled
The set values are scaled by the settings for AH-04/AH-05.
The set values are scaled by the settings for AJ-04/AJ-05.
Parameter
No.
Description
Data
A071 = 01 or 02
db-30 PID1 feedback data 1 monitor a) Conversion (Scale adjustment)
= (PID1 scale adjustment (at 100%) [AH-05] - PID1
scale adjustment (at 0%) [AH-04])
/ 100.00 * [Input (%)] + PID1 scale adjustment (at 0%)
[AH-04]
b) Internal conversion (%)
= ([Input (*1)] - PID1 scale adjustment (at 0%) [AH-04])
/ (PID1 scale adjustment (at 100%) [AH-05] - PID1
scale adjustment (at 0%) [AH-04]) * 100.00
*1. Equivalent to mon param read value (Same scale as
ones of AH-04, 05)
db-32 PID1 feedback data 2 monitor
db-34 PID1 feedback data 3 monitor
db-42 PID1 target value monitor
db-44 PID1 feedback data 1 monitor
FA-30 PID1 Set Value 1
FA-32 PID1 Set Value 2
FA-34 PID1 Set Value 3
AH-10 Set-point-1 setting for PID1
AH-12 PID1 Multi stage set-point 1 setting
AH-14 PID1 Multi stage set-point 2 setting
AH-16 PID1 Multi stage set-point 3 setting
AH-18 PID1 Multi stage set-point 4 setting
AH-20 PID1 Multi stage set-point 5 setting
AH-22 PID1 Multi stage set-point 6 setting
AH-24 PID1 Multi stage set-point 7 setting
AH-26 PID1 Multi stage set-point 8 setting
AH-28 PID1 Multi stage set-point 9 setting
AH-30 PID1 Multi stage set-point 10 setting
AH-32 PID1 Multi stage set-point 11 setting
AH-34 PID1 Multi stage set-point 12 setting
AH-36 PID1 Multi stage set-point 13 setting
AH-38 PID1 Multi stage set-point 14 setting
AH-40 PID1 Multi stage set-point 15 setting
AH-44 Set-point 2 setting for PID1
AH-48 Set-point 3 setting for PID1
Parameter
No.
Description
Data
A071 = 01 or 02
db-36 PID2 feedback data monitor a) Conversion (Scale adjustment)
= (PID1 scale adjustment (at 100%) [AJ-05] - PID1
scale adjustment (at 0%) [AJ-04])
/ 100.00 * [Input (%)] + PID1 scale adjustment (at 0%)
[AJ-04]
b) Internal conversion (%)
= ([Input (*1)] - PID1 scale adjustment (at 0%) [AJ-04])
/ (PID1 scale adjustment (at 100%) [AJ-05] - PID1
scale adjustment (at 0%) [AJ-04]) * 100.00
*1. Equivalent to mon param read value (Same scale as
ones of AJ-04, 05)
FA-36 PID2 Set Value
AJ-10 Set-point setting for PID2
db-55 PID2 output monitor
db-56 PID2 deviation monitor
