1-2 Preparation and System Configuration
You must prepare the following items to create user programs with functions of the DriveProgramming
in CX-Drive and execute the programs in the 3G3RX2 Series Inverter.
• 3G3RX2 Series Inverter
• Windows personal computer
(As for the supported OS (operation system), refer to CX-One User's Manual (W463).
• CX-Drive needs Ver 3.0 or higher.
(The CX-Drive is included in the FA Integrated Tool Package, CX-One.)
• Prepare the following PC-inverter connection cable.
Commercially-available USB cable (mini-B)
Additional Information
For how to install or upgrade the CX-Drive, refer to the CX-Drive Operation Manual (W453).
A terminal micro B terminal
