Omron CJ1M-CPU series User Manual

107
I/O Units Section 2-4
Mixed I/O Units
Note 1. The cable-side connector is not provided with Units equipped with cables.
Purchase the cable separately (see page 244), or use an OMRON Con-
nector-Terminal Block Conversion Unit or I/O Terminal (see page 247).
2. Although 16 I/O bits are allocated, only 8 of these can be used for external
I/O. This Unit is also treated as a 16-point I/O Unit in the I/O tables.
3. The Unit must be connected in one of the five positions (for CJ1-H CPU
Units) or three positions (for CJ1M CPU Units) next to the CPU Unit on the
CPU Rack. An I/O setting error will occur if the Unit is connected to other
positions on the CPU Rack or to any position on an Expansion Rack.
Name Specifications Model Number
of bits
allocated
Mountable Racks
CJ-series
CPU Rack
CJ-series
Expansion
Racks
24-V DC
Input/
Tran sis -
tor Out-
put Units
Sinking Fujitsu-compatible connector
Inputs: 24 V DC,16 inputs
Outputs: 12 to 24 V DC, 0.5 A, 16 outputs
(See note 1.)
CJ1W-MD231
(See note 1.)
32 Yes Yes
Fujitsu-compatible connector
Inputs: 24 V DC, 32 inputs
Outputs: 12 to 24 V DC, 0.3 A, 32 outputs
(See note 1.)
CJ1W-MD261
(See note 1.)
64 Yes Yes
MIL connector
Inputs: 24 V DC,16 inputs
Outputs: 12 to 24 V DC, 0.5 A, 16 outputs
(See note 1.)
CJ1W-MD233
(See note 1.)
32 Yes Yes
MIL connector
Inputs: 24 V DC, 32 inputs
Outputs: 12 to 24 V DC, 0.3 A, 32 outputs
(See note 1.)
CJ1W-MD263
(See note 1.)
64 Yes Yes
Sourcing MIL connector
Inputs: 24 V DC, 16 inputs
Outputs: 24 V DC, 0.5 A, 16 outputs,
load-short circuit protection (See note 1.)
CJ1W-MD232
(See note 1.)
32 Yes Yes
TTL I/O Units MIL connector
Inputs: TTL (5 V DC), 32 inputs
Outputs: TTL (5 V DC, 35 mA),
32 outputs
CJ1W-MD563
(See note 1.)
64 Yes Yes
B7A Interface Units 32 inputs, 32 outputs CJ1W-B7A22 64 Yes Yes
