I/O Table Settings List Section 2-8
2-8-2 CJ-series Special I/O Units
Note If the selected Unit, the number of input words, or the number of output words
is incorrect, a Special I/O Unit Setup error will be generated.
Name Model Unit type setting Addresses
per Unit
Input
Words
Output
Words
Analog Input Unit CJ1W-AD041 CS/CJ SIO Unit − Analog Input Unit 1 9 1
CJ1W-AD081 (-V1) 1 9 1
Analog Output Unit CJ1W-DA021 CS/CJ SIO Unit − Analog Output Unit 1 1 9
CJ1W-DA041 1 1 9
CJ1W-DA08V 1 1 9
Analog I/O Units CJ1W-MAD42 CS/CJ SIO Unit − Analog Input/Output Unit 1 5 5
Temperature Control
Units
CJ1W-TC001 CS/CJ SIO Unit − Temperature Control
Unit
2146
CJ1W-TC002 2 14 6
CJ1W-TC003 2 14 6
CJ1W-TC004 2 14 6
CJ1W-TC101 2 14 6
CJ1W-TC102 2 14 6
CJ1W-TC103 2 14 6
CJ1W-TC104 2 14 6
Position Control Units CJ1W-NC113 CS/CJ SIO Unit − Numerical Control Unit 1 3 2
CJ1W-NC213 1 6 4
CJ1W-NC413 2 12 8
CJ1W-NC133 1 3 2
CJ1W-NC233 1 6 4
CJ1W-NC433 2 12 8
PROFIBUS-DP Slave
Unit
CJ1W-PRT21 CS/CJ SIO Unit − Other SIO Unit 4 26 14
ID Sensor Units CJ1W-V600C11 CS/CJ SIO Unit − Other SIO Unit 1 10 ---
CJ1W-V600C12 2 20 ---
High-speed Counter
Unit
CJ1W-CT021 CS/CJ SIO Unit − High Speed Counter
Unit
42614
CompoBus/S Master
Unit
CJ1W-SRM21 CS/CJ SIO Unit − CompoBus/S Master
Unit
164
