The input response time cannot be changed for the CJ1W-INT01, and the
related portions of the Basic I/O Unit input time constants in the PLC Setup,
and the setting status in A220 to A259 will not be valid.
Input Signal Width Input signals must meet the following conditions.
3-6-2 CJ-series 32/64-point Basic I/O Units with Connectors
Units are available with either Fujitsu-compatible connectors (CJ1W-@D@@1)
or MIL connectors (CJ1W-@D@@2/3).
Unit ON time OFF time
CJ1W-INT01 0.05 ms min. 0.5 ms min.
ON OFF
Name Specifications Model Number
of bits
allocated
Page
DC Input Units Fujitsu-compatible connector
24 V DC, 32 inputs
CJ1W-ID231 32 514
Fujitsu-compatible connector
24 V DC, 64 inputs
CJ1W-ID261 64 517
MIL connector
24 V DC, 32 inputs
CJ1W-ID232 32 515
MIL connector
24 V DC, 64 inputs
CJ1W-ID262 64 519
Tran sis tor
Output
Units
With Sink-
ing Out-
puts
Fujitsu-compatible connector
12 to 24 V DC, 0.5 A, 32 outputs
CJ1W-OD231 32 543
Fujitsu-compatible connector
12 to 24 V DC, 0.3 A, 64 outputs
CJ1W-OD261 64 547
MIL connector
12 to 24 V DC, 0.5 A, 32 outputs
CJ1W-OD233 32 546
MIL connector
12 to 24 V DC, 0.3 A, 64 outputs
CJ1W-OD263 64 549
With
Sourcing
Outputs
MIL connector
24 V DC, 0.5 A, 32 outputs, load short-circuit protec-
tion
CJ1W-OD232 32 553
MIL connector
12 to 24 V DC, 0.3 A, 64 outputs
CJ1W-OD262 64 556
24-V DC
Input/
Tran sis tor
Output
Units
With Sink-
ing Out-
puts
Fujitsu-compatible connector
24 V DC, 16 inputs
12 to 24 V DC, 0.5 A, 16 outputs
CJ1W-MD231 32 525
Fujitsu-compatible connector
24 V DC, 32 inputs
12 to 24 V DC, 0.3 A, 32 outputs
CJ1W-MD261 64 531
MIL connector
24 V DC, 16 inputs
12 to 24 V DC, 0.5 A, 16 outputs
CJ1W-MD233 32 527
MIL connector
24 V DC, 32 inputs
12 to 24 V DC, 0.3 A, 32 outputs
CJ1W-MD263 64 533
With
Sourcing
Outputs
MIL connector
24 V DC, 16 inputs
24 V DC, 0.5 A, 16 outputs, load short-circuit protec-
tion
CJ1W-MD232 32 529
TTL I/O Units MIL connector
Inputs: TTL (5 V DC), 32 inputs
Outputs: TTL (5 V DC, 35 mA), 32 outputs
CJ1W-MD563 64 535
