I/O Table Settings List Section 2-8
2-8 I/O Table Settings List
The following settings are used in the I/O tables on the CX-Programmer.
2-8-1 CJ-series Basic I/O Units
Note If the selected Unit is incorrect, an I/O Table Setting error will be generated.
Name Model Unit type setting Addresses
per Unit
Input
Words
Output
Words
DC Input Units CJ1W-ID201 CS/CJ 8pt Unit − 8pt Input --- --- ---
CJ1W-ID211 16pt Unit − 16pt Input --- --- ---
CJ1W-ID231 32pt Unit − 32pt Input --- --- ---
CJ1W-ID232 32pt Unit − 32pt Input --- --- ---
CJ1W-ID261 64pt Unit − 64pt Input --- --- ---
CJ1W-ID262 64pt Unit − 64pt Input --- --- ---
AC Input Units CJ1W-IA111 16pt Unit − 16pt Input --- --- ---
CJ1W-IA201 16pt Unit − 16pt Input --- --- ---
24-V DC Input/Transistor Output Units CJ1W-MD231 32pt Unit − 32pt Mixed --- --- ---
CJ1W-MD232 --- --- ---
CJ1W-MD233 --- --- ---
CJ1W-MD261 64pt Unit − 64pt Mixed --- --- ---
CJ1W-MD263 --- --- ---
TTL I/O Unit CJ1W-MD531 32pt Unit − 32pt Mixed --- --- ---
CJ1W-MD533
CJ1W-MD561 64pt Unit − 64pt Mixed
CJ1W-MD563
B7A Interface Unit CJ1W-B7A14 64pt Unit − 64pt Input --- --- ---
CJ1W-B7A04 64pt Unit − 64pt Output --- --- ---
CJ1W-B7A22 64pt Unit − 64pt Mixed --- --- ---
Interrupt Input Unit CJ1W-INT01 Interrupt Unit (16 Bit) --- --- ---
High-speed Input Units CJ1W-IDP01 16pt Unit − 16pt Input --- --- ---
Relay Output Units CJ1W-OC201 16pt Unit − 16pt Output --- --- ---
CJ1W-OC211 16pt Unit − 16pt Output --- --- ---
Triac Output Unit CJ1W-OA201 16pt Unit − 16pt Output --- --- ---
Transistor Output Units with sinking outputs CJ1W-OD201 16pt Unit − 16pt Output --- --- ---
CJ1W-OD203 CS/CJ 8pt Unit − 8pt Out-
put
--- --- ---
CJ1W-OD211 16pt Unit − 16pt Output --- --- ---
CJ1W-OD231 32pt Unit − 32pt Output --- --- ---
CJ1W-OD233 32pt Unit − 32pt Output --- --- ---
CJ1W-OD261 64pt Unit − 64pt Output --- --- ---
CJ1W-OD263 64pt Unit − 64pt Output --- --- ---
Transistor Output Units with sourcing out-
puts
CJ1W-OD202 16pt Unit − 16pt Output --- --- ---
CJ1W-OD204 CS/CJ 8pt Unit − 8pt Out-
put
--- --- ---
CJ1W-OD212 16pt Unit − 16pt Output --- --- ---
CJ1W-OD232 32pt Unit − 32pt Output --- --- ---
CJ1W-OD262 64pt Unit − 64pt Output --- --- ---
