B7A Interface Unit Section 3-7
3-7-4 B7A Communications Specifications
Note 1. When separate power supplies are used, the B7A Interface Unit and B7A
Link Terminal are supplied by separate external power supplies.
2. When a common power supply is used, the B7A Interface Unit and B7A
Link Terminal are supplied by the same external power supply.
3. We recommend OMRON S8@@-series Power Supply Units for the exter-
nal power supplies.
4. The capacity of the external supply current does not include the capacity
required by the B7A Link Terminal.
5. The minimum input time is the minimum time required by the B7A Interface
Unit to read the input signals from the CPU Unit.
Item Specifications
Transmission
method
One-way time-sharing multiplex transmissions
Transmission delay
(communications
delay on
transmission path)
High-speed 3 ms typical, 5 ms max.
Standard 19.2 ms typical, 31 ms max.
Transmission points CJ1W-B7A14 64 inputs (4 ports)
CJ1W-B7A04 64 outputs (4 ports)
CJ1W-B7A22 32 inputs (2 ports), 32 outputs (2 ports)
External power
supply voltage
(See note 3.)
12 to 24 V DC (allowable voltage range: 10.8 to 26.4 V)
External supply
current
(See note 4.)
CJ1W-B7A14 40 mA min.
CJ1W-B7A04 150 mA min.
CJ1W-B7A22 80 mA min.
Minimum input time
(See note 5.)
High-speed 16 ms
Standard 2.4 ms
Transmission
distance
High-speed Power supply on one side
(common power supply)
10 m max.
50 m max. (with shielded cable)
Power supply on both sides
(separate power supplies)
10 m max.
100 m max. (with shielded cable)
Standard Power supply on one side
(common power supply)
100 m max.
Power supply on both sides
(separate power supplies)
500 m max.
Cables
VCTF, 0.75 mm
2
, 3 conductors (power supply on one side (common power supply))
VCTF, 0.75 mm
2
, 2 conductors (power supply on both sides (separate power supplies))
Shielded cable, 0.75 mm
2
, 3 conductors (power supply on one side (common power supply))
Shielded cable, 0.75 mm
2
, 2 conductors (power supply on both sides (separate power supplies))
