Programming Devices
Loop Controller Element Using CX-Process Tool Ver. 4.0 or later, select the Loop-control CPU
Unit/Process-control CPU Unit from the LC Type field in the LCB/LC001 Dia-
log Box. Then select either CJ1G-CPU42P, CJ1G-CPU43P, CJ1G-CPU44P,
orCJ1G-CPU45P, from the Number-Model pull-down list in the Unit Informa-
tion field.
CPU Unit Element Use CX-Programmer Ver. 5.0 or later. The CPU Unit functions are the same
as the CJ1G-CPU@@H, except for the differences provided in the previous
table. Therefore, select CJ1G-H as the device type when using CX-Program-
mer.
1,2,3... 1. Select New from the File Menu.
2. Select one of the following CPU Unit types in the Change PLC Dialog Box.
Reference Manuals • The CPU Unit functions are the same as the CJ1G-CPU@@H, except for
the differences provided in the previous table. Therefore, for details on the
CPU Unit functions, refer to the SYSMAC CJ Series Programmable Con-
trollers Operation Manual (W393), SYSMAC CS/CJ Series Programmable
Controllers Programming Manual (W394), SYSMAC CS/CJ Series Pro-
grammable Controllers Instructions Reference Manual (W340), and Com-
munications Commands Reference Manual (W342).
• For details on the Loop Controller functions (LCB@@ functional element)
refer to the section on SYSMAC CS/CJ Series Loop Control Boards, Pro-
cess-control CPU Units, Loop-control CPU Units Operation Manual
(W406).
Loop-control CPU Unit Device type CPU Unit type
CJ1G-CPU42P CJ1G-H CPU42
CJ1G-CPU43P CPU43
CJ1G-CPU44P CPU44
CJ1G-CPU45P CPU45
