13-5 Event Logs
13
13-5-2 Error Table
34A90000 hex Tag Data Link
Error
There were two or
more errors in a
connection as an
originator. The fol-
lowing are
excluded.
• The power supply to the target
node is OFF.
• Communications with the target
node stop.
• The Ethernet cable for Ether-
Net/IP is disconnected.
• The Ethernet cable for Ether-
Net/IP is disconnected.
• Noise
S page 13-40
34AA0000 hex Tag Refresh
Error
An unsupported
data area or
address range is
specified for the tag
data links.
• An unsupported data area or
address range was specified for
the tag data links.
S page 13-40
34AB0000 hex Basic Ether-
net Setting
Error
There is an illegal
TCP/IP setting.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S page 13-41
34AC0000 hex IP Address
Table Error
The IP address
table information is
incorrect.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S page 13-41
34AD0000 hex IP Router
Table Error
The IP router table
information is incor-
rect.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S page 13-42
34AE0000 hex Routing Table
Error
The routing table
information is incor-
rect.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S page 13-42
34AF0000 hex Ethernet
Advanced
Setting Error
There is an illegal
FINS setting.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S page 13-43
34B00000 hex Address Mis-
match
The host ID of the
local IP address is
inconsistent with
the FINS node
address. Or, the
last segment of the
local IP address is
inconsistent with
the setting on the
node address
switches.
• Th
e IP address conversion
method
is set to automatic gen-
eration, but the host ID of the
local IP address is inconsistent
with the FINS node address or
the last segment of the local IP
address is inconsistent with the
setting on the node address
switch.
S page 13-43
381C0000 hex Status Area
Layout Set-
ting Error
An error occurred in
the layout setting of
the EtherNet/IP
Unit.
• There is an error in the layout
settings of the EtherNet/IP Unit.
S page 13-44
54AE0000 hex Multiple
Switches ON
Error
More than one soft-
ware switch
changed to TRUE
at the same time.
• More than one software switch
changed to TRUE at the same
time. Or, another software
switch changed to TRUE before
processing was completed for a
previous software switch.
S U page 13-44
84E00000 hex IP Address
Duplication
Error
The same IP
address is used
more than once.
• The IP address of the Ether-
Net/IP port is also used as the
IP address of another node.
S page 13-45
