4 Programming Device
4-12
CP1E CPU Unit Hardware User’s Manual(W479)
If the USB driver cannot be installed automatically, use the following procedure to install it.
Windows Vista
Installing a Specified USB Driver
1
Turn ON the power supply to the PLC and connect the peripheral USB port on the
PLC to the personal computer using a USB cable.
2
The following dialog box will be dis-
played. Select Locate and install
driver software (Recommended).
3
The following dialog box will be dis-
played. Select I don’t have the disc.
Show me other options.
4
The following dialog box will be dis-
played. Click the Browse Button,
specify the following location, and
then click the Next Button.
C:\Program Files\OMRON\CX-
Server\USB\wind2000_XP\Inf
To Next Page
