Omron CP1E-ED

A-3
Appendices
CP1E CPU Unit Hardware User’s Manual(W479)
A-1 Dimensions
App
A-1-2 Option Boards
Unit: mm
Unit: mm
Unit: mm
CPU Units with 40 I/O Points (CP1E-40D-)
CPU Units with 60 I/O Points (CP1E-N60D-)
A-1-2 Option Boards
CP1W-CIF01 RS-232C Option Board
4-φ4.5
150
85
8
140
110 10090
90100110
185
195
4-φ4.5
8
85
35.9
37.3 35.9
5.1
16.5
16.5
0.15
13.5
19.7
