Omron CP1E-ED

Appendices
A-6
CP1E CPU Unit Hardware User’s Manual(W479)
Unit: mm
Unit: mm
Unit: mm
CP1W-32ER/ET/ET1 Expansion I/O Units with 32 Output Points
CP1W-20ED Expansion I/O Units with 20 I/O Points
CP1W-40ED Expansion I/O Units with 40 I/O Points
50
8
4 ‑ φ4.5
110 100 90
140
150
50
8
2 ‑ φ4.5
90 100±0.2
5
5
76±0.2
86
50
8
4 ‑ φ4.5
110 100 90
140
150
