2 Basic System Configuration and Devices

2-18

CP1E CPU Unit Hardware User’s Manual(W479)

 Other Devices Using PLC Internal Power Supply

Unit name Model number

Current consumption

5 VDC 24 VDC

Conversion Adapter CJ1W-CIF11 0.04A −

NT-AL001 0.15A

−

Programmable

Ter mi na l

Backlight

Green/Orange/Red

NV3W-MG20L 0.2A

−

Backlight

White/Pink/Red

NV3W-MR20L 0.2A

−
