Omron CPM2A - 11-2005 User Manual

1-1SectionCPM2A Features and Functions
7
1-1-2 Overview of CPM2A Functions
Main function Variations/Details
Interrupts
Interrupt inputs
4 inputs, see note 1.
Response time: 0.3 ms
Interval timer interrupts
1 input
Scheduled interrupts
p
Set value: 0.5 to 319,968 ms
Precision: 0.1 ms
One-shot interrupt
High-speed counters High-speed counter
1 input see note 2
No interrupt
1
i
npu
t
, see no
t
e
2
.
Differential phase mode (5 kHz)
Pulse plus direction input mode (20 kHz)
Up/down input mode (20 kHz)
Increment mode (20 kHz)
Count-check interrupt
(An interrupt can be generated when the
count equals the set value or the count
lies within a preset range.)
Interrupt inputs (counter mode)
4 inputs, see note 1.
No interrupt
p,
Incrementing counter (2 kHz)
Decrementing counter (2 kHz)
Count-up interrupt
Pulse outputs 2 outputs:
Single-phase pulse output without acceleration/deceleration (See note 3.)
10 Hz to 10 kHz
2 outputs:
Variable duty ratio pulse output (See note 3.)
0.1 to 999.9 Hz, duty ratio 0 to 100%
1 output:
Pulse output with trapezoidal acceleration/deceleration (See note 3.)
Pulse plus direction output, up/down pulse output, 10 Hz to 10 kHz
Synchronized pulse control 1 point, see notes 2 and 3.
Input frequency range: 10 to 500 Hz, 20 Hz to 1 kHz, or 300 Hz to 20 kHz
Output frequency range: 10 Hz to 10 kHz
Quick-response input 4 inputs, see note 1.
Minimum input signal width: 50 µs
Analog settings 2 controls (setting ranges: 0 to 200 BCD)
Input time constant Determines the input time constant for all inputs. (Settings: 1, 2, 3, 5, 10, 20, 40, or 80 ms)
Calendar/Clock Shows the current year, month, day of the week, day of the month, hour, minute, and
second.
