142
Setting the PF Key Section 4-19
Note For details on MV settings for heating and cooling control, refer to
MV Display for Heating and Cooling Control on page 84.
Setting Monitor/Setting Items
Pressing the PF Key in either the operation or adjustment level displays the
applicable monitor/setting items. Press the PF Key to display in order Monitor/
Setting Items 1 to 5. After Monitor/Setting Item 5 has been displayed, the dis-
play will switch to the top parameter in the operation level.
Note (1) Items set as disabled in the Monitor/Setting Items 1 to 5 parameters will
not be displayed, and the display will skip to the next enabled setting.
(2) While a monitor/setting item is being displayed, the display will be
switched to the top parameter in the operation level if the M Key or the
O Key is pressed.
Operating Procedure This procedure sets the PF Setting parameter to PFDP, and the Monitor/Set-
ting Item 1 parameter to 7 (Alarm Value 1).
Set
value
Setting Remarks
Monitor/Setting Symbol
0 Disabled ---
1 PV/SP/Multi-SP Can be set. (SP) ---
2 PV/SP/MV (See note.) Can be set. (SP) ---
3 PV/SP /Soak time remain Can be set. (SP) ---
4 Proportional band (P) Can be set. p
5 Integral time (I) Can be set. i
6 Derivative time (D) Can be set. d
7 Alarm value 1 Can be set. al-1
8 Alarm value upper limit 1 Can be set. al1h
9 Alarm value lower limit 1 Can be set. al1l
10 Alarm value 2 Can be set. al-2
11 Alarm value upper limit 2 Can be set. al2h
12 Alarm value lower limit 2 Can be set. al2l
13 Alarm value 3 Can be set. al-3
14 Alarm value upper limit 3 Can be set. al3h
15 Alarm value lower limit 3 Can be set. al3l
Operation Level
Initial Setting Level
1. Press the O Key for at least three seconds to move from the operation
level to the initial setting level.
2. Select the Move to Advanced Function Setting Level parameter by press-
ing the M Key.
C
25
100
PV/SP
in-t
5
Input Type
amov
-169
Move to Ad-
vanced Function
Setting Level
To Next Page
