Omron E5AN User Manual

185
Adjustment Level Section 5-4
This parameter measures the heater current from the CT input used for
detecting SSR short-circuits.
This parameter measures and displays the heater current value.
• HS alarms are not detected if the control output (heating) OFF time is
100 ms or less.
• ffff is displayed when 55.0 A is exceeded.
• If an HS alarm 2 alarm is output, the HA indicator will light and the No. 1
display for the leakage current 2 monitor will flash.
■ Related Parameters
HS alarm 1, HS alarm 2 (adjustment level): Page 184
HS alarm use (advanced function setting level): Page 235
Error Displays lcr2: Page 283
This parameter sets the current for the HS alarm to be output.
• An HS alarm is output when the leakage current value exceeds the set-
ting of this parameter.
• When the set value is 50.0, the HS alarm output is turned OFF. When the
set value is 0.0, the HS alarm output will turn ON.
■ Related Parameters
Leakage current 2 monitor (adjustment level): Page 185
HS alarm use, HS alarm latch, HS alarm hysteresis (advanced function set-
ting level): Page 235
lcr2 Leakage Current 2 Monitor
Heater burnout, HS alarms, and
heater overcurrent detection must be
supported (two CTs).
Alarm 1 must be assigned.
The HS Alarm parameter must be
set to ON.
Monitor range Unit
0.0 to 55.0 A
Function
Monitor
See
See
hs2 HS Alarm 2
Heater burnout, HS alarms, and
heater overcurrent detection must be
supported (two CTs).
Alarm 1 must be assigned.
The HS Alarm parameter must be
set to ON.
Setting range Unit Default
0.0 to 50.0 A 50.0
Function
Setting
See
See
