Omron E5AN User Manual

210
Initial Setting Level Section 5-7
• Select one of the following four alarm 3 types:
Deviation, deviation range, absolute value, or PV change rate alarm.
Refer to the alarm 1 type list. The 12: LBA (Loop Burnout Alarm) setting in
that list cannot be used.
■ Related Parameters
Alarm value 3: Page 173, Alarm value upper limit 3, Alarm value lower limit 3:
Page 175 (operation level)
Standby sequence reset: Page 221, Auxiliary output * open in alarm: Page
222, Alarm 3 hysteresis: Page 209, Alarm 3 latch: Page 227 (advanced func-
tion setting level)
• This parameter sets the transfer output type.
• The operation is shown in the following table.
■ Transfer Output Destination
■ Precision and User Calibration
Note Refer to SECTION 6 CALIBRATION for details on the calibration procedure.
alt3 Alarm 3 Type
Alarm 3 must be assigned.
Function
Setting
See
See
tr-t Transfer Output Type
There must be a transfer output or a
current output.
Control output 1 Control output 2 Transfer output
destination
Current output • No
• Relay output
• Voltage output (for driving
SSR)
Control output 1
• Relay output
• Voltage output (for driving
SSR)
•No
• Relay output
• Voltage output (for driving
SSR)
No
Precision User calibration
Transfer output ±0.3% FS Supported (See note.)
Simple transfer output ±0.3% FS Not supported.
