Omron E5AN User Manual

37
Wiring Terminals Section 2-2
Control Output 1 • Outputs are sent from terminals 1 and 2 with the E5CN, from pins 4 to 6
with the E5CN-U, and from pins 3 and 4 with the E5AN/EN/GN. The fol-
lowing diagrams show the available outputs and their internal equalizing
circuits.
• The following table shows the specifications for each output type.
E5CN/CN-U
Output type Specifications
Relay 250 VAC, 3 A (resistive load), electrical durability: 100,000
operations
Long-life relay
(using a triac)
250 VAC, 3 A (resistive load), electrical durability: 1,000,000
operations
Voltage (for driv-
ing SSR)
PNP type, 12 VDC ±15%, 21 mA (with short-circuit protec-
tion)
Current DC 4 to 20 mA/DC 0 to 20 mA, resistive load: 600 Ω max.
Resolution: Approx. 10,000
E5CN
E5AN/EN
L
+
−
L
+
−
+
−
L
L
+
−
E5GN
L
+
−
L
+
−
E5CN-U
Current
Current
Current
Voltage (for driving SSR)
Voltage (for driving SSR)
Voltage (for driving SSR)
Relay
Relay
Relay
Current
Voltage (for driving SSR)Relay
GND
GND
GND
v
+
v
+
v
+
v
+
v
+
v
+
1
2
1
2
1
2
4
5
6
4
5
6
4
5
6
4
3
4
3
3
4
+v
+
−
+v
+
−
L
L
